| Main | Biometric | Fingerprint | ||
| Live Finger Detection | Supported | |||
| RF Options | BSA2-OEPW | 125 KHz EM | ||
| BSA2-OHPW | 125KHz HID Prox | |||
| BSA2-OIPW | 13.56MHz MIFARE MIFARE Plus, DESFire/EV1, FeliCa, iCLASS SE/SR, NFC |
|||
| BSA2-OMPW | 13.56MHz MIFARE MIFARE Plus, DESFire/EV1, FeliCa, NFC |
|||
| Multi-Controller | Yes | |||
| Capacity | Max. User (1:1) | 500,000 | ||
| Max. User (1:N) | 100,000 | |||
| Max. Template (1:1) | 1,000,000 *two templates per finger |
|||
| Max. Template (1:N) | 200,000 *two templates per finger |
|||
| Max. Text Log | 5,000,000 | |||
| Max. Image Log | 50,000 | |||
| Interface | WiFi | 802.11 b/g | ||
| TCP/IP | Yes | |||
| RS-485 | 1ch Host or 1ch Slave (Selectable) |
|||
| RS-232 | No | |||
| Wiegand | 1ch In 1ch Out |
|||
| Input | 2 Inputs | |||
| Relay | 1 Relay | |||
| USB | Host | |||
| SD Card Slot | Up to 32GB | |||
| Hardware | CPU | 1.0GHz Quad Core | ||
| Memory | 1GB RAM + 8GB Flash | |||
| LCD | 5.0" IPS LCD Touch | |||
| LED Indicator | Multi-Color | |||
| Sound | 24bit/Voice DSP (Echo Cancellation) | |||
| Operating Temp. | -20° to 50°C | |||
| Tamper | Yes | |||
| Power | 12VDC | |||
| PoE | Yes | |||
| Dimensions | 155 x 155 x 40 (WxHxD mm) | |||
| Certificates | CE, FCC, KC, RoHS, REACH, WEE | |||
| Compatibility | BioStar 1.x | Yes | ||
| BioStar 2 | Yes | |||
